LilSpring Multi-purpose Waterers
Muliti-purpose Waterers
general livestock feature:
• One-piece body polyethylene construction
• No sharp edges
• Tough high-impact resistant “Rockite” material
• The durability to stand up to livestock abuse
• Resistance to corrosion
• 5-year warranty
• Removable dome for quick and easy access to valve area
• 2” to 3” (5 to 8 cm) urethane foam insulation
• Molded base unit anchors (stainless steel anchor bolts included)
• Sloped bottom for easy cleaning
• Sealed bottoms
Miraco Catalog PDF
Contact Wille Construction Miraco Dealer
LilSpring 2700
|
 |
| CAPACITY |
100 head sheep/goats |
| GALLONS |
6 (22.7 liters) |
| LENGTH |
28.75” (73 cm) |
| WIDTH |
17.5” (44.5 cm) |
| DRINKING HEIGHT |
14” (35.5 cm) |
| WEIGHT |
40 pounds (18.15 kg) |
| HEAT |
Optional 250 watt submersible heater |
|
|
LilSpring 2800/2801
|
 |
| CAPACITY |
30 head beef or horses |
| GALLONS |
4 (15 liters) |
| DIMENSIONS |
20” x 16” x 27” tall (51 x 41 x 69 cm) |
| DRINKING HEIGHT |
19” (48 cm) |
| VALVE |
Miraco automatic plastic |
| WEIGHT |
40 pounds (18 kg) |
| HEAT |
Optional 110 volt 250 watt submersible heater |
| INSTALL |
200 psi hose w/shut off valve included |
|
|
LilSpring 2900/2901
|
 |
| CAPACITY |
60 head beef or horses |
| GALLONS |
6 (23 liters) |
| DIMENSIONS |
30.5” x 16.5” x 27” (77.5 x 40.6 x 69 cm) |
| DRINKING HEIGHT |
19” (48 cm) |
| VALVE |
Miraco automatic plastic |
| WEIGHT |
Miraco automatic plastic |
| HEAT |
Optional 110 volt 250 watt submersible heater |
| INSTALL |
200 psi hose w/shut off valve included |
|
|
LilSpring 3000/3001
|
 |
| CAPACITY |
30 head beef
30 head horses
50 head sheep |
| GALLONS |
5 (19 liters) |
| DIMENSIONS |
24” x 22” x 21” (61 x 56 x 53 cm) |
| DRINKING HEIGHT |
16” (40 cm) |
| VALVE |
Miraco automatic plastic |
| WEIGHT |
48 pounds (22 kg) |
| HEAT |
Optional 110 volt 250 watt submersible heater |
|
|
LilSpring 3100/3101
|
 |
| CAPACITY |
100 head beef
50 head dairy |
| GALLONS |
8 (30 liters) |
| DIMENSIONS |
36” x 22” x 27” (91 x 56 x 69 cm) |
| DRINKING HEIGHT |
22” (55.8 cm) |
| VALVE |
Miraco automatic plastic |
| WEIGHT |
75 pounds (34 kg) |
| HEAT |
Optional 110 volt 250 watt submersible heater |
|
|
LilSpring 3200/3201
|
 |
| CAPACITY |
150 head beef
75 head dairy |
| GALLONS |
25 (95 liters) |
| DIMENSIONS |
48” x 24” x 29” (122 x 61 x 74 cm) |
| DRINKING HEIGHT |
24” (61 cm) |
| VALVE |
Miraco automatic plastic |
| WEIGHT |
98 pounds (45 kg) |
| HEAT |
Optional 110 volt 250 watt submersible heater |
|
|
LilSpring 3500
|
 |
| CAPACITY |
225 head beef
110 head dairy |
| GALLONS |
40 (152 liters) |
| DIMENSIONS |
42” x 42” x 26” (107 X 107 X 66 cm) |
| DRINKING HEIGHT |
26” (66 cm) |
| VALVE |
Miraco automatic plastic |
| WEIGHT |
145 pounds (65 kg) |
| HEAT |
Optional 500 watt heater, 110 or 220 volt |
|
|
|
